Bobcat E20 / Compact Excavators / Excavators

Equipment Specification

Unit of Measurement

Imperial Units Metric Units

Performance

Arm (stick) length used for dimensions & forces

4' 2" ft/in

Max dig depth

8' 6" ft/in

Max depth of vertical wall

6' 11" ft/in

Reach @ ground level

14' 0" ft/in

Dump height

8' 8" ft/in

Boom swing, right/left

60° / 80° deg

Bucket digging force

4,684 lbs

Engine

Engine make

Kubota

Engine model

D722-E4B

Net hp

13.3

Dimensions

Transport length

12' 1" ft/in

Transport height

7' 6.4" ft/in

Transport width

3' 3" - 4' 6" ft/in

Tail overhang over side

0" in

Weight

Operating weight

2.0 metric tons

Operating weight

4,306 lbs

Bucket

Bucket capacity, SAE heaped min-max

0.5 - 3.1 cu ft

Hydraulics

Total flow of main pumps, implement & swing

11.0 gpm

Max relief valve pressure

3,350 psi
