Liebherr T 284 / Rigid Frame Trucks / Off-Highway Trucks

Equipment Specification

Unit of Measurement

Imperial Units Metric Units

Body

Heaped capacity (2:1) (SAE)

-- cu yds

Struck capacity (SAE)

-- cu yds

Dump time, full cycle

50 sec

Heaped capacity (2:1) (SAE)

-- cu yds

Struck capacity (SAE)

-- cu yds

Dump time, full cycle

50 sec

Heaped capacity (2:1) (SAE)

-- cu yds

Struck capacity (SAE)

-- cu yds

Dump time, full cycle

50 sec

Dimensions

Overall length

51' 5" ft/in

Overall operating width

31' 8" ft/in

Overall height

27' 2" ft/in

Turning clearance radius

56' 5" ft/in

Overall length

51' 5" ft/in

Overall operating width

31' 8" ft/in

Overall height

27' 2" ft/in

Turning clearance radius

56' 5" ft/in

Overall length

51' 6" ft/in

Overall operating width

31' 10" ft/in

Overall height

27' 3" ft/in

Turning clearance radius

56' 5" ft/in

Payload & Weights

Payload rating

363 metric tons

Empty machine weight without liner

522,000 lbs

Payload rating

363 metric tons

Empty machine weight without liner

522,000 lbs

Payload rating

375 metric tons

Empty machine weight without liner

522,000 lbs

Engine, Drive

Engine make

MTU / Cummins

Engine model

20V4000; QSK 78

Gross power

4,023 / 3,755 / 3,650 / 3,500 hp

Net power

-- hp

Max speed loaded

40 mph

Engine make

MTU

Engine model

16V4000

Gross power

3,200 / 3,000 hp

Net power

-- hp

Max speed loaded

40 mph

Engine make

MTU / Cummins

Engine model

20V4000; QSK 78

Gross power

4,023 / 3,755 / 3,650 / 3,500 hp

Net power

-- hp

Max speed loaded

40 mph

Tires

Tires

56/80 R63; 59/80 R63

Tires

56/80 R63; 59/80 R63

Tires

59/80 R63
